Serfilco®
Spacesaver Filtration System
Materials to provide chemical resistance and maximum operating temperatures:
| • PVC (60ºC) | • PP (80ºC) |
| • CPVC (93ºC) | • PVDF (100ºC) |
CPVC provides compatibility to a wide range of metal finishing and PCB
applications up to 93ºC temperature.
It is ideal for chrome and electro-less nickel solutions without having to resort to the much more expensive PVDF material. PP and PVC are recommended for alkaline non cyanide zinc solutions.
• 316 stainless steel available for hot alkaline cleaners.
Filtration systems are available in a range of flow rates and cartridge capacities:
• 1 x 4" Cartridge Mini Labmaster 500 l/h to 26 x 40" Cartridge Spacesaver MegaFlo System 65 m3/h
• Maximum surface area over 50m2 with pleated cartridges
The choice of filter cartridge is yours:
• Premier washed wound
• Polypropylene spun
• Pleated absolute rated
